Applicable Standard
The instrument is designed and manufactured according to the People's Republic of China petrochemical industry standard SH / T 0090---"Engine Coolant Freezing Point Determination Method".It is applicable to the standard method to do the corresponding freezing point test.
Function Feature
● Imported compressor cascade refrigeration adopted, the minimum temperature: -70 °C, temperature control accuracy:± 0.1 °C.
● Desktop structure, the cold tank adopts the Dewar bottle with simple design, nice appearance, convenient operation, complete equipment.
● The latest LER lighting technology, observe clearly, not glaring.
● Mechanical automatic mixing function.
Technical Parameter
1. Power supply:AC(220±10%)V、50Hz.
2. Working cold trough:glass Dewar bottle
3. Cold trough temperature range:-70°C~50°C
4.Temperature control accuracy:±0.1°C.
5.Bath liquid stir: motor automatic stirring
6.Cooling System:the refrigeration compressor from Germany Danfoss .
7.Sample stirring:automation.
8.Working environment:≤30°C.
9.Relative humidity:≤85%.
10.Total power consumption::≤2000W.
Standard Configuration
No | Name | Unit | Qty |
1 | Main body | Set | 1 |
2 | Automatic stirring device | Set | 1 |
3 | Freezing point test tube | Piece | 1 |
4 | Thermometer rubber plug | Piece | 1 |
5 | Thermometer, -80°C~20°C | Pieces | 2 |
6 | Test tube rubber plug | Piece | 1 |
7 | Guided crystallization tube | Piece | 1 |
8 | Wire | Piece | 1 |
9 | Fuse | Pieces | 2 |
10 | Manual | Piece | 1 |
11 | Certification | Piece | 1 |
