Application:
NDJ-1,NDJ-4 spiral type viscometer is applicable to measuring the viscous resistance and absolute viscosity in the liquid,widely used for measuring the viscosity of grease, paint, plastic, food, drugs, adhesives and other fluids,and also a precise instrument for monitoring and controlling the product quality in the production.
Main Technical Parameters:
Model | NDJ-1 | NDJ-4 |
Measuring Range | 1-1*105 mPa.s | 1-2*106 mPa.s |
Rotor Specification | Standard with #1-4 rotor ( #0 rotor is optional,can measure low viscosity to 0.1-10m Pa.s) |
Rotor Speed | 6,12,30,60 r/min | 0.3,0.6,1.5,3,6,12,30,60 r/min |
Measuring Precision | ±5%(Newtonian liquid) |
Power Supply | AC220V± 10%,50HZ±10% |
Size | 280*275*380 | 280*350*390 |
Net Weight | 3.5 KG | 4.0 KG |
