Main Application
Distillate fuel oil oxidation stability tester (acceleration method) is designed and manufactured according to the requirements of SH/T 0175 "Distillation Fuel Oil Oxidation Stability Test (Acceleration Method)" of the People's Republic of China,and EN ISO 12205 2011
Features
1. Adopt a water bath structure.
2. The instrument is cooled by tap water.
3. The instrument comes with a light-shielding device to ensure protection from light during oxidation.
4. Large color LCD screen, embedded system control. There are automatic timing and alarm functions.
5. Equipped with black box and filter unit. The oxygen flow of the instrument is separately controlled and adjustable, and the oxidation and cooling processes are automatically completed at one time.
Technical Parameters
1. Power source: AC220V±10% 50Hz.
2. Heating power: ≤3.4KW.
3. Temperature control accuracy: 95.0±0.1°C.
4. Oxygen flow rate: 50ml/min±5ml/min.
5. Number of oxidation tubes: 6 channels, and 6 samples can be made at the same time.
6. Dimensions: 700mm * 440mm * 1345mm (including black box).
Configuration Table
Order | Name | Specification | Qty | Remark |
1 | Distillate fuel oil oxidation stability tester |
| 1 |
|
2 | Thermometer | 0~100°C | 1 |
|
3 | filter | M50 | 1 |
|
4 | Oxidation tube |
| 12(6+6) |
|
5 | Condenser |
| 6 |
|
6 | Filter bottle (with rubber stopper) |
| 1 |
|
7 | Vacuum system |
| 1 |
|
8 | Glue plug |
| 1 |
|
9 | Silicone tube | 6*9 | 5 |
|
10 | Black box |
| 1 |
|
11 | Filter |
| 1 |
|
12 | power cable |
| 1 |
|
13 | fuse |
| 2 |
|
14 | Manual, certificate |
| 2 |
|
