Technical characteristics
• Portable design: The instrument is lighter, easier to carry and use.
• Fast measurement: There is no need to wait after the instrument is turned on, and you can measure immediately to get the purity value quickly.
• Fast gas saving: The gas consumption is only about 0.5L (101.2kPa) during measurement.
• Self-locking connector: The self-locking connector imported from Germany is safe, reliable and free of air leakage.
• Data storage: Large-capacity design can store up to 100 sets of test data.
• Clear display: The LCD screen directly displays the purity value, time and date, and battery power.
• RS232 interface: It can be connected to a serial printer for data printing.
• Built-in power supply: built-in 4Ah rechargeable lithium battery, can work continuously for 10 hours at a time.
Technical Parameters
Purity | Testing range | 0%~100% |
Testing accuracy | ±0.5% |
Testing time | <2 minutes |
Ambient temperature | －40℃～＋60℃ |
Ambient humidity | 0～100％ RH |
Power supply | AC 220V |
Built-in rechargeable battery |
Battery performance | Charging time is more than 20 hours and can be used for 10 hours |
Weight | 3 kg |
Size | 250×100×300mm3 |
Working temperature | －30℃～＋50℃ |
